TDA4VM & RGB-IR GMSL2 Camera System: High-Performance Vision Processing Solution
Overcoming the limitation of the TI TDA4VM supporting only FPD-Link, this solution now supports the GMSL interface, the standard for automotive environments.
System Overview
By integrating the TI TDA4VM processor with the RGB-IR GMSL2 camera, this system delivers advanced AI-based vision processing capabilities for applications such as autonomous mobile robots (AMR), ADAS (Advanced Driver Assistance Systems), and industrial automation.
Key Features
1. TDA4VM Processor
High-Performance Computing: Includes Dual Arm Cortex-A72, C7x DSP, and AI Accelerators.
Machine Learning & Vision Processing: Delivers up to 8 TOPS of AI performance.
Multi-Camera & Sensor Support: Supports both GMSL2 and MIPI CSI-2 interfaces.
Diverse Connectivity Options: PCIe, USB 3.1, Gigabit Ethernet, and CAN-FD.
Flexible Development Environment: Supports ROS, Linux SDK, and Edge AI SDK.
Automotive-Grade Reliability: Optimized for real-time AI-based decision-making.
2. RGB-IR GMSL2 Camera
RGB-IR Mode: Capable of capturing Visible Light (RGB) and Infrared (IR) images simultaneously.
GMSL2 Interface: Enables low-latency data transmission over distances of up to 15m.
Automotive & Industrial Design: Provides optimal performance even in low-light conditions and harsh environments.
Applications
โ
Autonomous Robots โ Real-time AI-based navigationย
โ
ADAS โ Object detection and trackingย
โ
Smart Surveillance Systems โ AI-based real-time monitoringย
โ
Industrial Automation โ High-precision inspection and quality control
Why Choose This Solution?
Powerful AI Computational Performance: Supports real-time vision processing.
Multi-Camera Support: Provides stable and reliable connectivity.
High Reliability: Optimized for autonomous driving and vision-based applications.
More Information
๐ TI TDA4VM Official Pageย
๐ RGB-IR GMSL2 Camera Details
For more detailed inquiries, please contact sales@telelian.com.
